Mānuka included finish & specification

Cladding

Interior

Kitchen

MicroPro Radiata Pine timber feature face in variety of stains from light to dark.

To complement our timber features we utilise ColorCote corrugate iron walls and roofing in variety of colours. This brand offers incredible durability in all climates of New Zealand, whether that's the harsh summers or freezing cold of Central Otago, or the salty beach side of the Coromandel.

Mixture of exposed NZSIP and painted GIB.

Pine trims.

Rigid core flooring eliminates the need for toxic glues, it is waterproof, easy to clean and is child and pet friendly.

Bedrooms feature high quality New Zealand wool carpets.

Function, durability and aesthetics all work together to create harmony.

Selection of great colours with soft close hardware.

Oven, cooktop and rangehood included.

*Impression only - spec may vary

Bathroom

Laundry

Master Bedroom

An inviting space.

Wall hung vanity with two large draws with your choice of light timer, white or black finish.

Sleek and elegant tapware.

Acrylic shower as standard.

Five bar heated towel rails to give you that warm, dry towel every time you get out of the shower.

Kardean flooring.

*Mirror, vanity stone bowl & top not included.

Space & service allocation for washer and dryer to complete the household necessities.

Ample space for that king size bed, stunning large windows with tilt & turn window for access and great ventilation.

*Wardrobes are an additional cost.

Bedroom 2

Windows

Perfect for the children, visitors or as an office space.

*Wardrobes are an additional cost.

Black uPVC joinery.

Lightbridge Low-E double glazing.

See building plans further down the page for windows included in your build.

* Triple glazing available on request.

Appliances

Lighting & Electrical

Hot Water

60cm oven, 4 burner induction cooktop, dishwasher & rangehood included.

HPL switch gear in black or white with ample power sockets including a selection with multifunction charging ports.

Energy efficient LED downlights throughout the dwelling, including soffit area.

Soft floor lighting with sensors for the hallway and bathroom.

Soft LED strip under vanity, shower niche, and under kitchen cabinet.

Exterior lights with sensor.

All builds include an 220L electric cylinder or gas on-demand califont hotwater system.

Stiebel Eltron externally mounted Hotwater heatpump cylinders are available as an optional extra.

Floor Plan 76m2 - 2 bedroom

Floor Plan 70m2 - 2 bedroom

By the numbers

Floor area:
1 Bedroom: 60m2
2 Bedroom: 70m2
2 Bedroom: 76m2

Height: 4.2m

Bedrooms: 1 or 2

Decking: Not included

Optional upgrades (POA)

Head off grid with solar, greywater, and an incinerating toilet.

Full timber cladding, not a problem! We can offer LMA cladding for all walls.

Elegant tile shower, bathroom floor and skirting.

Timber floors? Certainly we can offer LMA or Forte engineered timber flooring.

Triple glazing, sure thing we have options for triple glazing and timber window joinery.

Full Birch Ply interior linings.

The Arbol Difference

Low-Energy use

uPVC Joinery

Continuous Fresh Air

For our Manuka model we use NZSIP 165mm R7.0 panels for the walls and 215mm R9.4 for the roof.

The floor is constructed from Laminated Veneer Lumber (LVL) and insulated with Earthwool Ecose insulation of R4.8.

Reduced thermal bridging and less than 0.65 ACH (air change per hour)

With heat recovery up to 90%

Resulting in up to 70% saving on your power bills.

Compare this to a Building Code legal minimum new home. (Latest H1 2023 Standard)

R2.5 Floor
R2 Walls
R6.6 Ceiling
6 ACH (air change per hour)
Energy recovery 0%

You can learn more about the Árbol difference here.

Unlike Aluminum, uPVC joinery is extremely thermally efficient. So you won't have crying windows and cold drafts.

They are UV resistant, won’t rot, corrode, or rust.

Feature European tilt & turn opening for security and ventilation.

Have great seals & locking cams for fantastic airtightness – resulting in less heat loss.

Require very little maintenance and are easy to clean.

LOW-E Lightbridge Argon filled double glazed glass completes the package by reflecting harmful UV light and reducing over heating in the summer months.

Contain up to 70% recycled materials.

Our Brink Flair 225 crossflow Mechanical Ventilation Heat Recovery system (MVHR) completes your high-performance home by continuously removing moisture and stale air, while returning fresh filtered air.

Best of all, the system recovers up to 90% of heat from the exhaust cycle (this includes heat created by showering & cooking) and returns it to the living environment.

The system is always on, very quiet and consumes almost no power as it only uses a small fan to circulate the air.

Prefabricated

Trusted Brand

Environmental Responsibility

Your abode is fully finished in our facility before delivery to you. That includes all plaster, paint and tiling.

Why? In one word - Efficiency.
Would Toyota build your car in your front yard?

Traditional on-site building is plagued with cost over runs, delays, additional waste, noise, and wasted time.

We work from a controlled environment:

75% of our builds are inside - so our team and your dwelling are not exposed to the elements - wind, rain, snow, and the sun = no more weather delays.

Security - all our materials and tools are safely stored inside our fenced, locked and constantly under video surveillance premises. This means our team can start and end the day quickly, no more carrying tools back and forth, everything is charged and ready to go. Materials are stored in our racking for quick access, and plenty of fixed lighting makes for a pleasant work environment during the short days of winter.

Reduced travel - one site for dwelling construction, no back and forth.

We are here to monitor all trade work, insuring high quality finish for you.

We don't take shortcuts, there is no "she'll be right" attitude at Árbol, we always strive for the best.

All our dwellings are inspected and fully consented by Central Otago District Council, so you can be certain your most important asset is legal and insurable.

We do our utmost to insure a smooth and fair transaction for all parties.

Our contracts are balanced and payment terms-based on procurement of materials, technical reports and work completed.

We have delivered 20 homes since 2022 - from Tutukaka at the top of the North Island to Seddonville on the South Islands West Coast.

We started our 24th build in August 2024.

We are not just renders, concepts and ideas on paper, but solid tangible products that have been delivered to our very happy clients.

Don't just take our word for it, see our client testimonials and learn more about each project at -Árbol In The Wild.

At Árbol we have an effective eco-system that benefits the environment and the climate.

Standard building materials typically have short life spans and require excessive maintenance - most of the time the original product is also harvested or created from unsustainable sources, not reusable or recyclable.

We have focused our efforts into sourcing a large percentage of our products from either sustainably harvested, manufactured, recycled, or reclaimed materials, additionally many of these are treated without harsh chemicals and require less maintenance - some examples include low VOC paints, NZ wool insulation, cladding made from old power poles, and uPVC windows & doors that are made from recycled plastics.

Using these materials reduces environmental impact while providing a greater resistance to New Zealand’s harsh climate.

Power is another important consideration moving to a sustainable future. Our homes are built to be low-energy use: With 40-63% less power consumption than the average new build, now a smaller thus, more affordable solar system can be used to supplement the home’s power and return excess to the grid.

The New Zealand building industry is an over 50% contributor to landfill. We can and do better - we store off cuts for future builds and separate recycling with - cardboard, hard plastics, soft plastics, polystyrene, metals, plaster, and glass. This has reduced our landfill waste by two thirds compared to on-site construction.

Árbol building better for you.
